Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A

Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A
Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A

Large Image :  Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A

Product Details:
Place of Origin: China
Brand Name: PASSIONAL
Model Number: 7S 24V 20A
Payment & Shipping Terms:
Minimum Order Quantity: 2-99 Pieces
Price: Negotiable

Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A

Description
Keywords: Battery BMS Board Product Name: Battery Management Systems
Application: Battery Packs Usage: Lithium Battery Packs
Number Of Layers: 3 Layers Communication: No
Size: 95*58*17MM Weight: 0.065kg
Temperature Protection: Yes Over Discharge Protection: Yes
Over Charge Protection: Yes Selling Units: Single Item
Single Package Size : 13X8X9 Cm Single Gross Weight: 0.400 Kg
Package Type: Bubble Pack And Carton Brand: Passional
High Light:

Wheelchair Lithium Battery BMS Board

,

PCB BMS 24V 7S 20A

,

24V 7S 30A Battery BMS Board

Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A



Battery BMS Board Description:

Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A, our work creates a BMS that is safe enough for you. The battery BMS board has been tested and is generally used with -go°C-7oc. The high-performance aluminum alloy radiator provides strong thermal protection and reduces the temperature rise of the protection board. The battery BMS board is safer in kind, intelligently balanced, and temperature controlled, making your battery safe and stable.



Battery BMS Board Parameter:

Over Charge Protection
Balance voltage
Overcharge detection voltage
4.25±0.05V Balance Detection voltage 4.18V
Overcharge detection delay time
1s Balance release detection voltage 4.18V
Overcharge release voltage 4.154±0.05V Balance current 30±5mA
Over-Discharge Protection
Overcurrent Protection
Over-discharge detection voltage
2.7±0.01V
Overcurrent protection current -
Over-discharge detection delay time
IMS
Overcurrent detection delay time 1s
Over-discharge release voltage
3.0±0.1V
Release condition
Cut short load
Short cycle protection Temp. Protection
Detection condition Out load short cycles Charge protection Temp. -5-50°C
Detection delay time 300±30 Discharge protection Temp. -20-70°C
Release condition Cut load NTC thermal sensor
Self-consumption
Working Temp.
Current consumption in normal operation <100uA Temperature. range -40/80℃
Sleep current(over-discharge) ≤20uA



Specification MOS Withstand Voltage Model Size/mm Weight/g
NCM 21S72V30A Common port with balance 100V 25A 125*62*12 1800g
NCM 21S72V35A Common port with balance 100V 25A 125*62*12 185g
NCM 21S72V45A Common port with balance 100V 25A 125*62*17
190g
NCM 21S72V50A Common port with balance
100V
25A 125*62*17 195g
NCM 21S72V60A Common port with balance 100V 25A 125*62*17 200g
NCM 21S72V70A Common port with balance 100V 25A 125*62*17 210g
NCM 21S72V100A Common port with balance 100V 25B 176*68*17 380g
NCM 21S72V120A Common port with balance 100V 25B 176*68*17
390g
NCM 21S72V140A Common port with balance 100V 25B 176*68*17 410g
NCM 21S72V200A Common port with balance 100V 25B 176*68*17 430g



Battery BMS Board FAQ:

1. What are the standard ports and separate ports? what is the difference?
We take 13S48V16A BMS as an example, joint port 16A means your charge cathode and discharge cathode are connected in the same point end(our P-), charge cathode and discharge cathode are used in the common connection port, so the charge current and discharge current are the same 16A. while the separate port is separately connected by charge cathode (C-) and discharge cathode (P-), so the charge current and discharge current are different, discharge current 16A, charge current 8A.
2. What is the balance function?
The working principle and function are as followings when your one cell voltage is up to alarm voltage(Li-ion up to 4.18V, Life Po4 up to (3.6V), then the cell Balance starts to work, balance resistance starts discharge with 35ma(when balance discharge starts to work, BMS will start a little heat up, which is the normal reflection), the cell is in both charging and discharging status, and others which are not reached to alarm voltage(Li-ion 4.18V, Life Po43.6V)are only in charging status, no discharging, when the fast cell voltage is reached to alarm voltage (Li-ion 4.25V, Life PO4 3.75V)BMS starts off power protection, all the other cells are all in the top of charging, this process will enable your battery charging in balance current, and your battery voltage are in balance status, but when your cell voltage difference are in a big range, then the balance can not be functioning.
3. The relationship between Battery capacity and BMS current?
There is no direct relationship between Battery capacity and BMS current, big capacity doesn`t mean a big battery but relies on continued current, that is to say, if your engine is powerful, you should choose a high current of BMS, it does not rely on battery capacity.




Wheelchair Lithium Battery BMS Board PCB BMS 24V 7S 20A 30A 0
