Product Details:
|
| Keywords: | Battery BMS Board | Base Material: | FR-4 |
|---|---|---|---|
| Copper Thickness: | 1/2OZ 1OZ 2OZ 3OZ | Board Thickness: | 2mm |
| Min. Hole Size: | 0.1mm | Min. Line Width: | 0.065mm |
| Min. Line Spacing: | 0.065mm | Surface Finishing: | HASL |
| Product Name: | Battery Management Systems | Application: | Battery Packs |
| Usage: | Lithium Battery Packs | Number Of Layers: | 1-2-4-6 Layers |
| Communication: | No | Size: | 125*62*17MM |
| Weight: | 0.185kg | Selling Units: | Single Item |
| Single Package Size : | 13X8X9 Cm | Single Gross Weight: | 0.400 Kg |
| Package Type: | Bubble Pack And Carton | Brand: | Passional |
| Highlight: | 12V 100A 4S BMS Balance,4S Solar Battery Management System,4S BMS Balance Common Port |
||
12V 100A 4S BMS Balance Common Port Solar Battery Management System
Battery BMS Board Description:
12V 100A 4S BMS Balanced Common Port Solar Battery Management System The new all-in-one BMS solution has six safety protection functions: drop protection, charging protection, overcurrent protection, NTC temperature protection, discharge protection and short circuit protection.
Battery BMS Board Parameter:
|
Over Charge Protection
|
Balance voltage
|
||
|
Overcharge detection voltage
|
4.25±0.05V | Balance Detection voltage | 4.18V |
|
Overcharge detection delay time
|
1s | Balance release detection voltage | 4.18V |
| Overcharge release voltage | 4.154±0.05V | Balance current | 30±5mA |
|
Over-Discharge Protection
|
Overcurrent Protection | ||
|
Over-discharge detection voltage
|
2.7±0.01V
|
Overcurrent protection current | - |
| Over-discharge detection delay time |
IMS
|
Overcurrent detection delay time | 1s |
| Over-discharge release voltage |
3.0±0.1V
|
Release condition
|
Cut short load |
| Short cycle protection | Temp. Protection | ||
| Detection condition | Out short load cycles | Charge protection Temp. | -5-50°C |
| Detection delay time | 300±30 | Discharge protection Temp. | -20-70°C |
| Release condition | Cut load | NTC thermal sensor | |
|
Self-consumption
|
Working Temp.
|
||
| Current consumption in normal operation | <100uA | Temperature. range | -40/80℃ |
| Sleep current(over-discharge) | ≤20uA | ||
| Specification | MOS Withstand Voltage | Model | Size/mm | Weight/g |
| NCM 21S72V30A Common port with balance | 100V | 25A | 125*62*12 | 1800g |
| NCM 21S72V35A Common port with balance | 100V | 25A | 125*62*12 | 185g |
| NCM 21S72V45A Common port with balance | 100V | 25A | 125*62*17 |
190g
|
| NCM 21S72V50A Common port with balance |
100V
|
25A | 125*62*17 | 195g |
| NCM 21S72V60A Common port with balance | 100V | 25A | 125*62*17 | 200g |
| NCM 21S72V70A Common port with balance | 100V | 25A | 125*62*17 | 210g |
| NCM 21S72V100A Common port with balance | 100V | 25B | 176*68*17 | 380g |
| NCM 21S72V120A Common port with balance | 100V | 25B | 176*68*17 |
390g
|
| NCM 21S72V140A Common port with balance | 100V | 25B | 176*68*17 | 410g |
| NCM 21S72V200A Common port with balance | 100V | 25B | 176*68*17 | 430g |
Battery BMS Board FAQ:
Q1. Do you have a current sample in stock?
A1: Most regular ones we have usually we will ship out 3 days after you paid
Q2. What's the delivery time for mass production?
A2: Usually 3-7days, it depends on the quantity, especially function and etc. we suggest checking delivery time case
by case.
Q3. OEM&ODM are available?
A3: Sure, OEM&ODM are welcome and the Logo can be customized too.
Q4. What is your MOQ?
A4: 1pc is OK. small orders are also welcome
