Product Details:
|
| Keywords: | LiFePO4 Battery BMS | Base Material: | FR-4 |
|---|---|---|---|
| Copper Thickness: | 1/2OZ 1OZ 2OZ 3OZ | Min. Line Spacing: | 0.065mm |
| Application: | Battery Packs | Usage: | Lithium Battery Packs |
| Communication: | No | Size: | 125*63*16MM |
| High Light: | 24S 72V 70A LiFePO4 Battery BMS,LiFePO4 BMS Common Port PCB,125*63*16MM LiFePO4 Battery BMS |
||
24S 72V 70A LiFePO4 Battery BMS Common Port PCB 125*63*16MM
LiFePO4 Battery BMS Description:
The lithium iron phosphate battery is a lithium-ion battery using lithium iron phosphate (LiFePO4) as the positive electrode material and carbon as the negative electrode material.
LiFePO4 batteries have the advantages of high working voltage, high energy density, long cycle life, good safety performance, low self-discharge rate and no memory effect.
LiFePO4 Battery BMS Parameter:
| Model Number: | PLFP-7270 | Product name: | Battery Management Systems |
| Package Type: | bubble pack and carton | Application: | Battery Packs |
| Brand Name: | Passional | Usage: | Lithium Battery Packs |
| Base Material: | FR-4 | Number of Layers: | 1-2-4-6 Layers |
| Copper Thickness: | 1/2OZ 1OZ 2OZ 3OZ | Communication: | no |
| Board Thickness: | 2mm | Size: | 125MM*63MM*16MM |
| Min. Hole Size: | 0.1mm | Weight: | 0.165kg |
| Min. Line Width: | 0.065mm | Selling Units: | Single item |
| Min. Line Spacing: | 0.065mm | Single package size: | 13X8X9 cm |
| Surface Finishing: | HASL | Single gross weight: | 0.300kg |
Our Services:
1. We offer We provide customers with one-stop procurement services.
2. Here you can find all the main accessories related to lithium batteries.
3. Save time and energy for customers.
LiFePO4 Battery BMS FAQ:
Q:1. OEM&ODM are available?
A: Sure, OEM&ODM are welcome and the Logo can be customized too.
Q:2. The relationship between Battery capacity and BMS current?
A: There is no direct relationship between Battery capacity and BMS current, big capacity doesn`t mean a big battery, but relies on
continue current, that is to say, if your engine is powerful, you should choose a high current of BMS, it does not rely on battery capacity.
Q:3. Whether my BMS damaged?
A: if you want to judge if the BMS is damaged, please take the following steps, to test if each cell voltage is the same as with the voltmeter. if the cell voltage difference is over 1.0V, the fault is displayed that it cannot run far, no power supply at the start range, short charge time, all these issues are almost caused by battery cells, if BMS damaged is displayed as no charge, no discharge, no discharge while the battery has voltage.
